Hot Box Resin
Ⅰ. For efficient core making of non-ferrous metals, cast iron, and cast steel, hot box resin for coated sand is a good choice.
Ⅱ. With good disintegration and easy cleaning, hot box resin for coated sand simplifies the post-casting process.
Ⅲ. Hot box resin for coated sand is ideal for forming complex sand cores, providing excellent performance and adaptability in precision casting applications.
Package Specification: 240kg/ iron drum
Shelf Life: 12 months
Production Cycle: 7-10 days
Supporting Hardener: FR series hardener
- Information
Hot Box Resin for Foundry
| Model | Viscosity （20℃) (mPa.s） | Density （20℃) (g/cm³） | Total Acid (%) | Applicable Scope | Shelf Life |
| HC01 | 1.10-1.20 | ≤10 | 3-5 | Compatible With FR201 | 12 Months |
| HC02A | 1.05-1.25 | ≤10 | 6-8 | Compatible With FR204S | 12 Months |
| HC06 | 1.0-1.30 | ≤10 | 12.5-14.5 | Compatible With FR206S | 12 Months |
Introduction
The hot box resin for foundry acts as a binder that cures when exposed to heat. Its curing process occurs in two stages: in the first stage, the curing agent releases a strong acid under heating conditions; in the second stage, this strong acid catalyzes rapid curing of the hot box resin for foundry. The binder system consists of two components—Component I is a furfuryl alcohol-modified urea-formaldehyde resin, while Component II serves as the curing agent.
Features
• Our hot box resin for casting offers high strength while requiring less resin, helping to lower production costs.
• It cures rapidly, boosts production efficiency, and reduces energy consumption.
• With low viscosity, hot box resin for casting mixes easily with sand and ensures excellent core sand flowability.
• Hot box resin for casting we produced also provides strong moisture resistance, allowing for extended sand core storage time.
of Hot Box Resin for Foundry:Hot box resin for coated sandcomponent II is a curing agent.
FAQ
Q: Why are our Prices of hot box resin for casting more Competitive?
A: Direct from the factory – Thanks to our factory's strong production capabilities, Xinda is able to eliminate middlemen and avoid unnecessary markups. This allows us to maintain steady purchasing volumes, secure better pricing, and ensure a stable, reliable supply. Long-term partnership focus – We prioritize building long-term relationships with our customers. That's why we're willing to operate on lower profit margins while maintaining high product quality, passing more value on to our clients.
Q: Can we Place Customized Order?
A: Yes, we already own thousands of customized filters models in multiple sizes and shapes. And we are capable of new type customized production.
Q: How Can We Handle it if there's Quality Problem aAter Payment?
A: We are willing to provide technical support with professional team during and after delivery.
Q: How Can We Make Sure About the Quality After We Put the Order?
A: We will implement raw material tests before production and the product quality inspection reports by high precision instruments will be sent to you before deliver.
Q: How Long is your Delivery Time?
A: Our production cycle is 7-10 days in general, 5-7 days in emergency. There are also available urgent transportation method for your choice.
