Organic Warm Box Resin
Ⅰ. Low-formaldehyde formula is adopted in our warm box resin for aluminum castings to minimize harmful gas emissions.
Ⅱ. Efficient molding and precise dimensional control are ensured by our warm box resin for aluminum castings.
Ⅲ. High thermal and initial strength make our warm box resin a good choice for forming complex aluminum castings.
Package Specification: 25kg /iron drum
Shelf Life: 12 months
Production Cycle: 7-10 days
Supporting Hardener: HW series hardener
- Information
High Strength Organic Warm Box Resin
High strength organic warm box resin adopts an innovative formula, which is suitable for efficient core making of aluminum castings. It shows excellent structural stability, energy saving effect and good demoulding performance during use, and is closer to the production requirements of green environmental protection. The binder system includes three components, component I is furan resin, component II is curing agent, and component III is additive.
Features
• Our high strength organic warm box resin features low resin addition while maintaining exceptional strength.
• With remarkably fast curing speed, this organic warm box resin for foundry significantly enhances production efficiency.
• Porosity defects in castings can be effectively minimized thanks to the low gas emission of our organic warm box resin for foundry.
• Castings become easier to clean due to the excellent disintegration properties of our organic warm box resin for foundry.
How to Use It
• Addition ratio of each component
FW400: 1.4%-1.6 (accounting for sand weight), GW06: 0.45-0.55% (accounting for sand weight), AW07: 0.1% (accounting for sand weight).
• Sand mixing process
When using an intermittent sand mixer, first mix the sand and resin for 45 seconds, then add the curing agent and mix for 45 seconds, and finally add the additive and mix for 45 seconds. After mixing, sand is produced and cores are made.
• Selection of curing temperature and curing time
Curing temperature: 150-230℃, curing time: 5-60s, the thicker the sand core, the longer the curing time; the higher the curing temperature, the faster the curing speed, and the curing temperature is too low or the time is too short, which will cause incomplete curing of the sand core.
Parameters
| Item | Model | Appearance | Viscosity (20℃) (mPa.s) | Density (20℃) (g/cm³) | Free Aldehyde (%) | Total Acid (%) |
| Furan Resin | FW400 | Reddish-brown Transparent Liquid | ≤40 | 1.13-1.20 | ＜0.5 | - |
| Curing Agent | HW06 | Light Yellow to Dark Brown Transparent Liquid | ≤350 | 1.25-1.30 | - | 13.5-15.5 |
| Promoter | AW07 | Light Yellow | ≤10 | 0.80-0.85 | - | - |
Why are our Prices more Competitive?
Direct from the factory – Thanks to our factory’s strong production capabilities, Xinda is able to eliminate middlemen and avoid unnecessary markups. This allows us to maintain steady purchasing volumes, secure better pricing, and ensure a stable, reliable supply. Long-term partnership focus – We prioritize building long-term relationships with our customers. That’s why we’re willing to operate on lower profit margins while maintaining high product quality, passing more value on to our clients.
Can we Place Customized Order?
Yes, we already own thousands of customized filters models in multiple sizes and shapes. And we are capable of new type customized production.
How Can We Handle it if there’s Quality Problem aAter Payment?
We are willing to provide technical support with professional team during and after delivery.
How Can We Make Sure About the Quality After We Put the Order?
We will implement raw material tests before production and the product quality inspection reports by high precision instruments will be sent to you before deliver.
How Long is your Delivery Time?
Our production cycle is 7-10 days in general, 5-7 days in emergency. There are also available urgent transportation method for your choice.
