Water-Based Coating
Ⅰ. Low VOC emissions, reduced environmental impact, and non-flammable formulation make this coating a safer and more sustainable alternative to solvent-based options.
Ⅱ. Its non-flammable nature allows for safer storage, transport, and handling—eliminating fire and explosion risks while lowering insurance and regulatory costs.
Ⅲ. Compatible with a wide range of casting techniques—including resin sand, water glass sand, and lost foam processes—ensuring broad application flexibility.
Main Aggregates: Graphite Powder, Zircon Sand
Application Scope: Cast Iron, Cast Steel, and Non-Ferrous Metals
shelf Life: 6 month
Package: 25-40 kg Small Buckets, Ton Containers
- Information
Water Based Casting Coating
Xinda's water based casting coating is an eco-friendly solution designed for sand mold, core, and metal mold casting processes. Using water as the main solvent, it significantly reduces VOC emissions, eliminates flammable risks, and enhances workplace safety. Ideal for use in resin sand, water glass sand, and lost foam casting, the water based coating for sand casting forms a protective refractory layer between the mold and molten metal—effectively improving surface finish and preventing defects.
Features
• Eco-Friendly and Safe: Water-based formula of eco-friendly water based coating eliminates fire hazards, reduces VOCs, and supports safer working conditions.
• Low Gas Emission: Minimizes porosity and blowhole defects by emitting very little gas during pouring.
• Excellent Sand Adhesion Resistance: Water based coating for sand casting forms a dense, uniform layer with strong thermal strength and resistance to cracking or bubbling.
• Smooth Casting Surface: Reduces surface roughness, simplifies post-casting cleaning, and improves final product quality.
• High Compatibility: Water based coating for sand casting suitable for both ferrous and non-ferrous alloys across various casting methods.
Instructions for Use
• Stirring: Open the container and stir thoroughly using a pneumatic stirrer to ensure uniform suspension.
• Baume Measurement: Use a Baume meter to test the eco-friendly water based coating's density. Adjust viscosity through dilution based on application method (brushing, dipping, or spraying).
• Mold Preparation: Clean the water based coating for casting surface using compressed air to remove any loose particles.
• Application: Apply evenly from top to bottom and left to right. Ensure uniform thickness (recommended 0.3–0.5 mm depending on casting requirements).
• Drying: Place the coated mold in a drying oven until completely dry before pouring.
Water-based Coating
| Model | Aggregate | Density (25℃) g/cm³ | Baumé Degree | Colour | Application Range | Application Method |
| ST6580 | Aluminum Silicate | 1.70-1.90 | 50-70 | Beige paste | Medium and small steel castings, alloy steel castings heavy-wall cast iron castings and non-ferrous alloys | Dipping Brushing Spraying |
| ST6345 | Graphite-Aluminum Silicate | 1.30-1.50 | 30-35 | Red paste | Automotive parts production lines, all types of resin san | |
| ST6011 | Mixed multi-grade refractory materials | 1.40-1.60 | 40-50 | Gray paste | All types of resin sand, especially suitable for 3D printing casting process | |
| ST6086 | Aluminum Silicate | 1.60-1.40 | 32-35 | Grayish black paste | Cast iron resin sand proces | |
| ST6318 | Zircon Powder | 1.90-2.10 | 65-75 | White paste | Medium and large carbon steel, alloy steel and heat-resistant steel castings | |
| ST6160 | Composite Zircon Flour | 1.80-2.10 | 60-70 | Grayish white paste | Small carbon steel, alloy steel, heat-resistant steel or high-grade cast iron casting | |
| ST6590G | Mixed multi-grade refractory materials | 1.30-1.40 | 50-60 | Brown powder | Furan resin sand, lost foam casting | |
| ST6345G | Graphite-Aluminum Silicate | 1.26-1.36 | 30-35 | Red powder | Automotive parts production lines, all types of resin sand | Dipping Spraying |
Eco-friendly Water Based Coating for Casting Eco-friendly water based coating
Why are our Prices more Competitive?
Direct from the factory – Thanks to our factory’s strong production capabilities, Xinda is able to eliminate middlemen and avoid unnecessary markups. This allows us to maintain steady purchasing volumes, secure better pricing, and ensure a stable, reliable supply. Long-term partnership focus – We prioritize building long-term relationships with our customers. That’s why we’re willing to operate on lower profit margins while maintaining high product quality, passing more value on to our clients.
Can we Place Customized Order?
Yes, we already own thousands of customized filters models in multiple sizes and shapes. And we are capable of new type customized production.
How Can We Handle it if there’s Quality Problem aAter Payment?
We are willing to provide technical support with professional team during and after delivery.
How Can We Make Sure About the Quality After We Put the Order?
We will implement raw material tests before production and the product quality inspection reports by high precision instruments will be sent to you before deliver.
How Long is your Delivery Time?
Our production cycle is 7-10 days in general, 5-7 days in emergency. There are also available urgent transportation method for your choice.
