Alkaline Phenolic Resin And Supporting Curing Agent
Ⅰ. High Strength – Alkaline phenolic binders for casting enables reduced resin addition without compromising mold integrity.
Ⅱ. Environmental Performance – Alkaline phenolic binders for casting improves working conditions by minimizing harmful emissions.
Ⅲ. Excellent Recyclability – Eco-friendly phenolic resin supports high reuse rates of reclaimed sand, lowering material and disposal costs.
Packaging: 250kg/iron drum
Shelf Life: 12 months
Production Cycle: 7-10 days
Supporting Hardener: HQG series hardener
- Information
Alkaline Phenolic Resin
The self-hardening alkaline phenolic resin process, also known as the α-set method, involves mixing sand with alkaline phenolic resin and an organic curing agent. The mixture cures at room temperature to form strong, precise molds and cores.
This binder system is especially suitable for the production of alloy steel, carbon steel, high manganese steel, ductile iron, and aluminum alloy castings. As an eco-friendly phenolic resin, it offers lower emissions and excellent environmental compatibility.
Advantages of the HQG Curing Agent
• Low Emissions – The alkaline-based formula significantly reduces the release of harmful gases.
• High Reclaimability –Alkaline phenolic resin curing agent have good collapsibility and high sand recyclability help reduce disposal costs.
• Broad Applicability – Eco friendly phenolic resin widely used in precision manufacturing, including aerospace blades and automotive engine blocks.
How to Use
• Add theHQG curing agent to the sand and mix well.
• Then add the alkaline phenolic resin curing agent and continue mixing.
• Total mixing time: 5–60 seconds, depending on equipment and production scale
• Recommended Dosage:
‒ Resin: 1.1–2.0% of sand weight
‒ Curing Agent: 20–25% of resin weight
(Dosage may vary depending on ambient temperature and required demolding time.)
Parameters
| Model | Density (25℃) g/cm³ | Viscosity (25℃) ≤mPa.s | Free Formaldehyde (%) | PH | Remarks |
| JF-103A | 1.20-1.30 | ≤150 | ≤0.1 | ≥12 | Environment-friendly High Activity Shelf life (﹤25℃) 3 Months |
| JF-103B | 1.20-1.30 | ≤150 | ≤0.1 | ≥12 | Low VOC High Activity Shelf life (﹤25℃) 3 Months |
| JF-200 | 1.20-1.30 | ≤150 | ≤0.1 | ≥12 | Fast Curing High Activity Shelf life (﹤25℃) 3 Months |
| JF-106 | 1.20-1.30 | ≤150 | ≤0.1 | ≥12 | High Viscosity Ideal Regeneration Shelf life (﹤25℃) 3 Months |
| JF-300 | 1.20-1.30 | ≤150 | ≤0.1 | ≥12 | Lower VOC Shelf Life (﹤25℃) 3 Months |
| JF-200H | 1.20-1.30 | ≤150 | ≤0.1 | ≥12 | Environment-friendly High Activity Shelf life (﹤25℃) 3 Months |
| HQG Curing Agent Model | Apppreance | Density (℃) g/cm³ | Viscosity (25℃) ≤mPa.s | Ester Content (%) | Remarks |
| HQG1 | Colorless Transparent Liquid | 1.0-1.25 | ≤25 | ≥98 | Fast Curing Mixed Together with HQG20 |
| HQG10 | 1.0-1.25 | ≤25 | ≥98 | 10 Min Demoulding at RoomTorrperature Mixed Together with HQG20 | |
| HQG20 | 1.0-1.25 | ≤25 | ≥98 | 20 Min Demoulding at Normal Temperature | |
| HQG60 | 1.0-1.25 | ≤25 | ≥98 | 60 Min Demoulding at Normal Temperature | |
| HOG90 | 1.0-1.25 | ≤25 | ≥98 | 90 Min Demoulding at Normal Temperature | |
| HQG240B | 1.0-1.25 | ≤25 | ≥98 | 240 Min Demoulding at Normal Temperature |
| ZQ Curing Agent Model | Apppreance | Density (℃) g/cm³ | Viscosity (25℃) ≤mPa.s | Ester Content (%) | Remarks |
| ZQ0 | Colorless Transparent Liquid | 1.0-1.25 | ≤20 | ≥98 | Sand Temperature 0°C Demolding after 20 Minutes |
| ZQ10 | 1.0-1.25 | ≤20 | ≥98 | Sand Temperature 10°C Demolding after 20 Minutes | |
| ZQ20 | 1.0-1.25 | ≤20 | ≥98 | Sand Temperature 20°C Demolding after 20 Minutes | |
| ZQ30 | 1.0-1.25 | ≤20 | ≥98 | Sand Temperature 30°C Demolding after 20 Minutes | |
| ZQ40 | 1.0-1.25 | ≤20 | ≥98 | Sand Temperature 40°C Demolding after 20 Minutes |
